Vacuum tumbler mixing machine for chemical industry

Quick Details

Packaging Details:	high quality wooden case and independent container.
Delivery Detail:	25-45 days

1.tumbler mixing machine
2.Multifunctional mixer
3.Frequency control
4.Blending & shearing
5.ISO9001,ISO14001,CE

Vacuum tumbler mixing machine for chemical industry

Mixer machine

1.Introduction:

1). Powerful and high efficient multi-functional disperser, do well in dispersing and shearing. mixer machine

2). Also do very well in balanced mixing. industrial blender

3). Equipped with four groups of blades, two for shearing and dispersing with high speed, other two for mixing with slow speed. machine

4). Equipped with inverter for frequency control.

5). Very well sealed, vacuum and high pressure environment are available, can effectively dislodge the bubbles.

disperser

6). The cylinder cover and the blades can be lifted and fallen hydraulically.

7). Equipped with two stainless steel tanks.

8). Widely used in mixing and dispersing high-viscosity liquid things.

mixer machine

2. Main technical parameters of the dispersion mixer machine:

Model	Volume (L)	Drive Motor Power (KW)		Drive Motor Power (KW)		Vacuum Degree (MPa)	Remarks
Model	Volume (L)	Stir	Dispersion	Stir	Dispersion	Vacuum Degree (MPa)	Remarks
QF-5	2	1.1	1.1	22.3	0 - 1450	-0.098	The data in this table is only for reference, the actual data can be designed as the detailed requirements and needs. Or decided by the material viscosity and other requirements.
QF-20	3	2.2	2.2*2	22.3	0 - 1450
QF-50	20	202	3*2	22.3	0 - 1000
QF-100	50	3	4*2	22.3	0 - 1000
QF-200	100	4	5.5*2	22.3	0 - 1000
QF-300	200	5.5	11*2	22.3	0 - 1000
QF-500	300	11	15*2	22.3	0 - 1000
QF-1000	500	15	22*2	22.3	0 - 1000
QF-2000	1000	30	37*2	22.3	0 - 1000
QF-4000	1500	45	55*2	22.3	0 - 1000
1). Lifting mode: Hydraulic lift and descend. 2). Heating or cooling can be designed as needs. 3). The pressure range: -0.1 ~ 0.3 MPa 4). Speed control mode: inverter for frequency control
